BimmerWorld BMW Wheel Spacers (Set/Pair) - 5x120

Lightweight, hubcentric, CNC machined spacers for most BMWs. Choose from 5mm, 12mm, 15mm, or 20mm sizes.

+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -

  •
  •

Price:
$99.99

Our BimmerWorld Wheel Spacer Sets are specifically designed to fit your BMW's 72.6 mm hub, retaining the proper hub centric design* while adding highly desired track width. They're designed to work with factory BMW wheels and nearly all aftermarket wheels. Whether you need a spacer set for correct wheel fitment, clearance for a set of big brake calipers or if you just want to widen your track width, we have the correct spacer to fit your needs.

  • Precision-machined lightweight design
  • 100% 6061-T6 aluminum alloy - black anodized for corrosion resistance
  • Spacer thickness clearly marked on rim
  • Ledge around inner rim for prying off stuck spacers
  • Machined pocket on inner bearing surface to reduce spacer sticking
  • Extra large holes to accommodate 12 and 14 mm bolts or studs

Note 1: hub, spacer, and wheel must fit together with zero gap between them. A gap between any component is a cause for failure. Check for a snug fitment with no wobble on each component. Click this link to learn more and watch a video of our paper test to ensure a proper and safe fitment.

Note 2: Due to the thin width of the 5mm spacer, the wheel will rest on the normal hub of the car. Therefore the spacer is designed flat.

Note 3: 10mm spacers are considered a custom fit. If your hub is deeper than 9.5mm the lip will have to be trimmed down. 10mm spacers also do not fit Kosei or TA16 wheels with a 45° chamfer on the back of the mounting hub.

Sold per pair. Spacers fit all 5x120 BMW applications, excluding the E39 5-Series and some E70 X5 models..

Spacer set does NOT include extended-length bolts - sold separately.

Bolt Thread LengthCorrelating Wheel Spacer Width
26-28mmstock bolt length
28mm0-3mm
32mm5-8mm
35mm8-10mm
37mm10-12mm
39mm12-15mm
42mm15-18mm
45mm18-20mm
47mm20mm


Please contact us if you will be incorporating our wheel bolts with spacers of different widths than what is listed.

BMW started changing over wheel bolt size and thread pitch around 2011 (some even earlier). If you are unsure of the size you need, please call for assistance.

Watch for wheel spacer installation tips:





BMW Fitments:

1 Series
E82 / E88 (08-13) > 128i
E82 / E88 (08-13) > 135i
E82 / E88 (08-13) > 135is
E82 / E88 (08-13) > 1M (11-12)
2 Series
F22 / F23 (2014+) > 228i
F22 / F23 (2014+) > 228i xDrive
F22 / F23 (2014+) > M235i
F22 / F23 (2014+) > M235i xDrive
3 Series
E30 (84-91) > M3
3 Series
E36 (92-99) > 318i M42
E36 (92-99) > 318i M44
E36 (92-99) > 318ic M42
E36 (92-99) > 318ic M44
E36 (92-99) > 318is M42
E36 (92-99) > 318is M44
E36 (92-99) > 323ic
E36 (92-99) > 323is
E36 (92-99) > 325i
E36 (92-99) > 325ic
E36 (92-99) > 325is
E36 (92-99) > 328i
E36 (92-99) > 328ic
E36 (92-99) > 328is
E36 (92-99) > M3 (1995)
E36 (92-99) > M3 (96-99)
3 Series
E36/5 (95-98) > 318ti M42
E36/5 (95-98) > 318ti M44
3 Series
E46 (99-05) > 323Ci
E46 (99-05) > 323i
E46 (99-05) > 325Ci
E46 (99-05) > 325i
E46 (99-05) > 325xi
E46 (99-05) > 328Ci
E46 (99-05) > 328i
E46 (99-05) > 330Ci
E46 (99-05) > 330i
E46 (99-05) > 330xi
E46 (99-05) > M3
3 Series
E90 / E91 / E92 / E93 (06-13) > 325i
E90 / E91 / E92 / E93 (06-13) > 325xi
E90 / E91 / E92 / E93 (06-13) > 328i
E90 / E91 / E92 / E93 (06-13) > 328xi
E90 / E91 / E92 / E93 (06-13) > 330i
E90 / E91 / E92 / E93 (06-13) > 330xi
E90 / E91 / E92 / E93 (06-13) > 335d
E90 / E91 / E92 / E93 (06-13) > 335i
E90 / E91 / E92 / E93 (06-13) > 335is
E90 / E91 / E92 / E93 (06-13) > 335xi
E90 / E91 / E92 / E93 (06-13) > M3
3 Series
F30 / F31 / F34 (2012+) > 320i
F30 / F31 / F34 (2012+) > 320i xDrive
F30 / F31 / F34 (2012+) > 328d
F30 / F31 / F34 (2012+) > 328d xDrive
F30 / F31 / F34 (2012+) > 328i
F30 / F31 / F34 (2012+) > 328i xDrive
F30 / F31 / F34 (2012+) > 335i
F30 / F31 / F34 (2012+) > 335i xDrive
3 Series
F80 (2015+) > M3 (2015+)
4 Series
F32 / F33 / F36 (2014+) > 428i
F32 / F33 / F36 (2014+) > 428i xDrive
F32 / F33 / F36 (2014+) > 435i
F32 / F33 / F36 (2014+) > 435i xDrive
4 Series
F82 / F83 (2015+) > M4 (2015+)
5 Series
E28 (82-88) > 524td
E28 (82-88) > 528e
E28 (82-88) > 533i
E28 (82-88) > 535i
E28 (82-88) > M5 (87-88)
5 Series
E34 (89-95) > 525i M20
E34 (89-95) > 525i M50
E34 (89-95) > 530i
E34 (89-95) > 535i
E34 (89-95) > 540i
E34 (89-95) > M5 (91-95)
5 Series
E60 / E61 (04-10) > 525i
E60 / E61 (04-10) > 525xi
E60 / E61 (04-10) > 528i
E60 / E61 (04-10) > 528xi
E60 / E61 (04-10) > 530i
E60 / E61 (04-10) > 530xi
E60 / E61 (04-10) > 535i
E60 / E61 (04-10) > 535xi
E60 / E61 (04-10) > 545i
E60 / E61 (04-10) > 550i
E60 / E61 (04-10) > M5
5 Series
F10 / F11 (2011) > 528i N52
F10 / F11 (2012-2016) > 528i N20
F10 / F11 (2012-2016) > 528i xDrive N20
F10 / F11 (2011+) > 535i
F10 / F11 (2011+) > 535i xDrive
F10 / F11 (2011+) > 550i
F10 / F11 (2011+) > 550i xDrive
F10 / F11 (2011+) > M5 (2011+)
6 Series
E24 (77-89) > 630CSi
E24 (77-89) > 633CSi
E24 (77-89) > 635CSi
E24 (77-89) > M6
6 Series
E63 / E64 (04-10) > 645Ci
E63 / E64 (04-10) > 650i
E63 / E64 (04-10) > M6
6 Series
F12 / F13 (2012+) > 640i
F12 / F13 (2012+) > 650i
F12 / F13 (2012+) > 650iX
F12 / F13 (2012+) > M6
7 Series
E32 (88-94) > 735i
E32 (88-94) > 735iL
E32 (88-94) > 740i
E32 (88-94) > 740iL
E32 (88-94) > 750iL
7 Series
E38 (95-01) > 740i
E38 (95-01) > 740iL
E38 (95-01) > 750iL
7 Series
E65 / E66 (02-08) > 745Li
E65 / E66 (02-08) > 745i
E65 / E66 (02-08) > 750Li
E65 / E66 (02-08) > 750i
E65 / E66 (02-08) > 760Li
7 Series
F01 / F02 (2009-2015) > 740Li
F01 / F02 (2009-2015) > 740i
F01 / F02 (2009-2015) > 750i
F01 / F02 (2009-2015) > 750Li
F01 / F02 (2009-2015) > 750Li xDrive
F01 / F02 (2009-2015) > 760Li
8 Series
E31 (91-97) > 840Ci
E31 (91-97) > 850CSi
E31 (91-97) > 850Ci
X Series
E53 (00-06) > X5 3.0i M54
E53 (00-06) > X5 4.4i M62 4.4L (99-03)
E53 (00-06) > X5 4.4i N62
E53 (00-06) > X5 4.6is M62
E53 (00-06) > X5 4.8is N62
X Series
E83 X3 (04-10) > X3 2.5i
E83 X3 (04-10) > X3 3.0i
X Series
E84 X1 (2009+) > X1 28i
E84 X1 (2009+) > X1 28i xDrive
E84 X1 (2009+) > X1 35i xDrive
X Series
F25 X3 (2014+) > X3 sDrive28i
F25 X3 (2011+) > X3 xDrive28i
F25 X3 (2011+) > X3 xDrive28d
F25 X3 (2011+) > X3 xDrive35i
X Series
F26 X4 (15-18) > X4 xDrive 28i
F26 X4 (15-18) > X4 xDrive 35i
F26 X4 (15-18) > X4 xDrive M40i
Z Series
E36/7 / E36/8 Z3 (96-02) > Z3 1.9
E36/7 / E36/8 Z3 (96-02) > Z3 2.3
E36/7 / E36/8 Z3 (96-02) > Z3 2.5
E36/7 / E36/8 Z3 (96-02) > Z3 2.8
E36/7 / E36/8 Z3 (96-02) > Z3 3.0
E36/7 / E36/8 Z3 (96-02) > Z3 M - S52
E36/7 / E36/8 Z3 (96-02) > Z3 M - S54
Z Series
E85 / E86 Z4 (03-08) > Z4 2.5i M54
E85 / E86 Z4 (03-08) > Z4 3.0i M54
E85 / E86 Z4 (03-08) > Z4 3.0i N52
E85 / E86 Z4 (06-08) > Z4 3.0si N52
E85 / E86 Z4 (03-08) > Z4 M
Z Series
E89 Z4 (2009+) > Z4 sDrive28i
E89 Z4 (2009+) > Z4 sDrive35i
E89 Z4 (2009+) > Z4 sDrive35is
