Rod Bearing Overhaul Kit (Basic), OEM - E46 M3 4/03+

Bare minimum bearings, gaskets, hardware, and BMW oil for late E46 M3

+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -

  •

Price:
$684.99

There are multiple ways to replace the rod bearings on E46 M3 and this kit includes the bare minimum basics for replacement with the subframe and steering rack removed. Our preference is to support the engine from above and remove the subframe with the steering rack and control arms still attached. It sounds like a lot of parts but is actually the fewest number of bolts/disconnections to make. All parts are Genuine or from an OEM supplier. This kit includes Genuine BMW 10W60 engine oil.

Fits M3 models from 4/2003 production date.

S54 rod bearing kit includes:
6 x 11247835439, Genuine BMW bearing shell, red, standard size
6 x 11247835440, Genuine BMW bearing shell, blue, standard size
12 x 11247834310, Genuine BMW M10 connecting rod bolt
1 x 11137834886, oil pan cover gasket
1 x 11131437237, oil pan gasket
1 x 11431707164, dipstick tube o-ring
1 x 11411401769, suction pipe o-ring
2 x 32411093596, power steering supply hose crush washer
2 x 32411093597, power steering outlet hose crush washer
2 x 80326, Red Line Assembly Lube (0.75oz)
1 x 11427833769, Mahle oil filter
6 x 83212365944, Genuine BMW 10W60 engine oil

Connecting rod bolts are included in this kit for late model M3. Cars produced from 2/2003 have a M10 connecting rod bolt that is stretched when properly torqued so they must be replaced. The bolts in this kit are the original factory rod bolts (stronger and reusable ARP bolts are also available, inquire).

This kit includes parts for unbolting the steering rack and subframe from the chassis. This includes the crush washers used for the power steering pump on the engine but does not include any other hardware for subframe removal. Most hardware can be re-used so this kit favors the DIY or shop that only needs the basics. Obviously additional other parts can also be replaced at the same time - motor mounts, tie rods, boots, oil pan bolts, etc - contact us for a package deal!

These are Genuine BMW bearings for the S54 engine. Treated WPC bearings are also available (see other kits below).

Genuine BMW 10W60 oil is included. We prefer Red Line but won't discourage you from using the factory-approved oil, especially if your warranty dictates it. Red Line 15W50 is our preference because of it's superior characteristics in nearly ever spec.

BMW Fitments:

3 Series
E46 (4/2003-2006) > M3
