Head & Top End Gasket Set, BMW - E39 M5, Z8 (S62)

Extensive gasket and seal package for S62 work above the engine block. Original replacement for BMW part #11121407805

+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -

  •

Price:
$855.30

This head gasket set for E39 M5 and E52 Z8 Roadster has all of the gaskets and seals associated with nearly any work done above the engine block, including head gasket replacement, intake manifold removal, VANOS and camshaft work, and more. It's good planning to have a top-end and bottom-end gasket on hand in your garage because you never know when you need a gasket in a pinch. Gasket sets are like having your very own BMW parts department at your finger tips!

The head gasket is sold separately (see below). Head gaskets are available in more than one thickness to account for a shaved or milled cylinder head. Use a stock thickness if you are not shaving the head.

Instead of buying just the head gasket (BMW part #11127833733 and 11127833734) you can get all of the other gaskets and seals needed to complete the job. This S62 top end gasket set includes:

1 x 11120001269, valve cover profile gasket (bank 1)
1 x 11120001278, valve cover profile gasket (bank 2)
2 x 11121406744, top cover profile gasket
20 x 11121437395, valve cover nut grommet
6 x 11121721879, valve cover collar screw rubber seal
2 x 11127830119, rear cover o-ring seal
2 x 11140001186, upper timing case gasket set
2 x 11141736758, upper chain tensioner gasket ring
2 x 11151406790, oil separator connector gasket seal
2 x 07119963072, VANOS oil hose gasket ring
4 x 07119963129, VANOS oil hose gasket ring
2 x 07119963042, VANOS connector gasket ring
4 x 11311317318, VANOS o-ring
2 x 11311317732, VANOS o-ring
2 x 11361406377, VANOS o-ring
2 x 11361406868, VANOS o-ring
2 x 11411306082, VANOS o-ring
2 x 11361406838, VANOS cover gasket
1 x 11361407956, VANOS pressure hose o-ring
4 x 12141748398, camshaft sensor o-ring
2 x 11349063193, valve stem seal kit
4 x 11531406249, coolant connector o-ring
6 x 11121406247, coolant pipe profile gasket
1 x 11531710055, coolant pipe o-ring
1 x 11611406657, air plenum profile gasket
4 x 11611406747, air plenum o-ring
4 x 11611406807, throttle gasket ring
1 x 11727505259, air pump valve gasket
2 x 07119901511, secondary air hose o-ring
3 x 11627505789, exhaust manifold gasket
1 x 11627509677, exhaust manifold gasket
2 x 18301728734, exhaust downpipe gasket ring

Additional parts such as the head bolts, other hardware, and sensors are sold separately (see below).

Symptoms of head gasket failure include: white residue (tapioca) in the valve cover, under the oil filler cap, and in drained oil, low coolant (not caused by failure in cooling system), low oil, oil leak onto exhaust manifold, and loss of power from loss of compression. Cooling system trouble on the S62 must be addressed quickly as the aluminum head is easily damaged if overheating occurs.

This is a Genuine BMW S62 head gasket set with a two year warranty. Buying a Genuine part will usually be more expensive than an OEM or aftermarket brand but you are assured that it meets BMW's designs for fitment, performance, and longevity. It will also be the very latest design, incorporating any updates or revisions that an aftermarket brand typically will ignore.

Because this kit fits multiple models it may include duplicate or redundant parts.

BMW Fitments:

5 Series
E39 (97-03) > M5 (00-03)
Z Series
E52 Z8 (00-03) > Z8 Roadster (2000-2003)
