Top-End Gasket Set, Elring - E90 325i/330i, E60 525i/530i, E85 Z4, N52 -10/06

Comprehensive gasket and seal package for N52 head replacement. Direct equivalent to BMW part #11127548921

+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -

  •

Price:
$178.99

Head gasket is NOT included with this kit. See below for links.

BMW puts these gasket sets together to aid in replacing the head gaskets on the N52 engine in 2006 E90 325i/330i, E60 525i/530i, and E85/E86 Z4.

Instead of buying only the head gasket, this kit includes all of the other gaskets and seals needed to do the job. See the complete list below. Note that BMW put this kit together to fit multiple models and some extra parts may be included that you won't use. Additional parts such as the head gasket, head bolts, other hardware, sensors, and hoses are sold separately.

Gasket set includes:
1 x 11127528242, Valvetronic sensor gasket
1 x 11127581215, valve cover gasket set
1 x 11317534251, Timing chain tensioner gasket ring
1 x 11367507729, non-return valve o-ring
2 x 11367548459, VANOS solenoid o-ring set
1 x 11377516302, Valvetronic Actuator gasket
1 x 11428637821, oil filter housing gasket
1 x 11537545278, Coolant hose flange o-ring
1 x 11617533329, Intake manifold connector o-ring
1 x 11617547242, Intake manifold profile gaskets
1 x 13627515272, Intake manifold pressure sensor o-ring
1 x 11727506214, cover gasket
2 x 12141748398, camshaft position sensor o-ring
1 x 13547522361, Throttle body gasket ("preformed seal")
1 x 13547582931, Throttle body gasket (not used for these cars)
6 x 13641437487, fuel injector upper o-ring
6 x 13647531313, fuel injector lower o-ring
6 x 18407530606, exhaust manifold gasket ring
2 x 18107549447, exhaust manifold-to-cat gasket

Symptoms of head gasket failure include: white residue (tapioca) in the valve cover, under the oil filler cap, and in drained oil, low coolant (not caused by failure in cooling system), low oil, oil leak onto exhaust manifold, and loss of power from loss of compression. Cooling system trouble on the M62 must be addressed quickly as the aluminum heads are easily damaged if overheating occurs.

This is an OEM Top-End Gasket Set for N52 engines manufactured by Elring Klinger - an original supplier to BMW for many gaskets and seals. As an OEM it meets all of BMW's original design, fitment, and performance requirements and is TUV approved. OEM parts are the best alternative to more expensive Original BMW parts because they are virtually identical without the inflated price tag. This part has a two year warranty.

BMW Fitments:
3 Series
E90 / E91 / E92 / E93 (06-13) > 325i
E90 / E91 / E92 / E93 (06-13) > 325xi
E90 / E91 / E92 / E93 (06-13) > 330i
E90 / E91 / E92 / E93 (06-13) > 330xi
5 Series
E60 / E61 (04-10) > 525i N52 (2006-2007)
E60 / E61 (04-10) > 525xi N52 (2006-2007)
E60 / E61 (04-10) > 530i N52 (2006-2007)
E60 / E61 (04-10) > 530xi N52 (2006-2007)
Z Series
E85 / E86 Z4 (03-08) > Z4 3.0i N52
E85 / E86 Z4 (03-08) > Z4 3.0si N52
