SPL Race Front Adjustable Upper Control Arms - E82, E9X, F8X

Lightweight, tubular arms with premium FK bearings for ultimate precision on track

+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -



Lowering your E82 1-series, E9X 3-series, F87 M2, F80 M3, or F82 M4 involves compromises that you can either live with or correct using more specialized parts. This front upper control arm (tension strut or thrust arm) is the latter - positioning the control arm for optimum alignment during the full range of motion. The adjustable tube allows you to use a custom caster setting. Rod ends and spherical bearings eliminate flex and binding inherent in the factory rubber bushings, reducing deflection and alignment change under load. Spacers are included to correctly position the ball joint with the new roll center on lowered vehicles.

Designed for track/racing use only. There is no mounting position for a headlight adjusting rod. Special droop-limiters in the shocks are not required with these arms. Use of solid and spherical bushings will have more noise and harshness than any other material and are not recommended for street use.

F8X Wheel Size Note: these arms are excellent for track wheels and tires up to 10.0-10.5" and 285-295 widths. To fit 11.0" and 305-315 tires we had to change the control arms, strut body, and camber plates. If you're happy with 285-295 tires, or drive the car on the street sometimes, these "standard width" arms are the recommended choice. If you plan for dedicated track or race use and want to run 305-315 tires all the time, see our GTMore full suspension package (click here or see link below).

SPL racing suspension parts are designed and manufactured in the USA from premium materials. SPL has a foundation in road racing, time trials, and drift competition which require precise suspension and alignment settings that can only come from spherical and solid mounts. Their parts are made with high-grade aluminum and titanium and use CNC machining and advanced production techniques to achieve to tight tolerances and light weight. FK Spherical Bearings include a Teflon inner liner for quieter and longer service life. SPL Parts have a limited one year warranty.

BMW Fitments:

1 Series
E82 / E88 (08-13) > 128i
E82 / E88 (08-13) > 135i
E82 / E88 (08-13) > 135is
E82 / E88 (08-13) > 1M (11-12)
2 Series
F87 (2016+) > M2 Competition S55 (2019+)
F87 (2016+) > M2 N55 (2016-2018)
3 Series
E90 / E91 / E92 / E93 (06-13) > 325i
E90 / E91 / E92 / E93 (06-13) > 328i
E90 / E91 / E92 / E93 (06-13) > 330i
E90 / E91 / E92 / E93 (06-13) > 335d
E90 / E91 / E92 / E93 (06-13) > 335i
E90 / E91 / E92 / E93 (06-13) > 335is
E90 / E91 / E92 / E93 (06-13) > M3
3 Series
F80 (2015-2018) > M3 (2015-2018)
4 Series
F82 / F83 (2015-2020) > M4 (2015-2020)
