Tie Rod Locking Plate, M3-spec - E36, Z3

Required to properly install a new tie rod assembly

+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -

  •

Price:
$37.99

The lock plate prevents the tie rod from backing out of the steering rack. When installed correctly with the "tab" of the lock plate bent over the tie rod, the tie rod cannot rotate backwards and off the rack. Most of the time these cannot be re-used once the tab is bent over so a new lock is recommended with new tie rods or if the tie rod is removed from the car. Sold per lock. A Genuine BMW part.

This part number is from the M3 but works on all E36 and Z3. The M3 lock plate is thicker than the non-M and acts like a steering rack stop to help prevent the tire from rubbing on the inner fender. On non-M cars you might notice the steering reaches full lock sooner.

BMW Fitments:

3 Series
E36 (92-99) > 318i M42
E36 (92-99) > 318i M44
E36 (92-99) > 318ic M42
E36 (92-99) > 318ic M44
E36 (92-99) > 318is M42
E36 (92-99) > 318is M44
E36 (92-99) > 323ic
E36 (92-99) > 323is
E36 (92-99) > 325i
E36 (92-99) > 325ic
E36 (92-99) > 325is
E36 (92-99) > 328i
E36 (92-99) > 328ic
E36 (92-99) > 328is
E36 (92-99) > M3 (1995)
E36 (92-99) > M3 (96-99)
3 Series
E36/5 (95-99) > 318ti M42
E36/5 (95-99) > 318ti M44
Z Series
E36/7 / E36/8 Z3 (96-02) > Z3 1.9
E36/7 / E36/8 Z3 (96-02) > Z3 2.5
E36/7 / E36/8 Z3 (96-02) > Z3 2.8 97-98
E36/7 / E36/8 Z3 (96-02) > Z3 2.8 99-00
E36/7 / E36/8 Z3 (96-02) > Z3 3.0
E36/7 / E36/8 Z3 (96-02) > Z3 M - S52
E36/7 / E36/8 Z3 (96-02) > Z3 M - S54
