Ground Control Camber/Caster Plates - F8X M3/M4, F87 M2 Competition

Performance-optimized adjustable mounts to correct front camber and caster

+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -

  •


  •

Price:
$658.99 – $713.99

Ground Control Camber/Caster Plates for your F80 M3, F82 M4, and F87 M2 Competition are based on their race-proven designs but with special features to optimize them for street-use. Both camber and caster can be adjusted independently to correct or dial in alignment settings. Ground Control parts are covered with a limited lifetime warranty.

A Ground Control exclusive is the use of two separate bearings to manage load instead of the more typical single spherical. The strut shaft is supported by a proprietary spherical bearing. This supports the strut during side loads and range of motion only. The weight of the car is supported by another, separate needle bearing made specifically for Ground Control with an incredibly high axial rating of 12,100lbs. The two bearing layout greatly reduces the load and strain that a single bearing must support, which means less wear, longer life, quieter operation, and better performance.

M2/M3/M4 Street Camber Plate features:
  • No cutting or modification required for install or use
  • CNC machined aluminum plates
  • Anodized or plated components for corrosion resistance
  • Aircraft-grade, sealed waterproof spherical and needle bearings
  • Dual bearing layout has less load demands than a single bearing design
  • Isolated urethane bushing to absorb NVH - no metal-on-metal contact
  • Steel slider inserts
  • 30mm of camber adjustment
  • Fast adjustment of camber and caster
  • Aerospace-grade materials
  • Rebuildable if you need a bearing or hardware
  • Upper spring perch included
  • Strut-specific hardware included

Select your spring size and shock type from the menus above. The correct bearings, spacers, and hardware will be built into the camber plate for you. Ground Control applications cover all common spring sizes and many popular stock and performance dampers. Please select your required spring size and bolt spec from the drop-downs. F8X M3s and M4's were originally built with 3-bolt strut towers (-1/'15). Cars built after 1/'15 were supplied with 5-bolt strut towers (including M2 Competition).

Spring Sizes: 2.25", 60mm (2.3"), 2.5", or any spring that uses the stock upper spring plate including sport/lowering springs.

Shock Type: AST, Bilstein, H&R, KONI, KW, MCS, Moton, Ohlins, and Stock/OEM. If your damper is not in the list, please select "Other" and one of our reps will contact you.

Ground Control has been engineering suspension mounts for competition use since 1980. Their camber plates are based on this rich history of custom suspensions for all types of driving - street, track, and mixed use. Each camber plate is a ground-up design for its intended use, not a compromise. Ground Control-branded parts have a limited lifetime warranty (bearings excluded).

If you need assistance selecting the correct options, please reach out to us via chat, email, or phone. Our expertise in BMW suspensions is unparalleled and we're happy to get you the right parts. In rare cases we may need to contact you during the order process to verify specs or get additional information.

BMW Fitments:

2 Series
F87 LCI (2019+) > M2 Competition
3 Series
F80 (2015+) > M3 (2015+)
4 Series
F82 / F83 (2015+) > M4 (2015+)
