APEX ARC-8 Wheel

Strong, lightweight, flow-formed, classic design

+ -
+ -
+ -
+ -
+ -
+ -
+ -
+ -

  •

  •

Price:
$298.99 – $448.99

APEX ARC-8 wheels have become one of the most sought after wheels for both track and street, and with good reason. They're light, strong, and are specifically designed to fit your BMW. Plus, they just happen to have a classic design that never looks old.

The split-spoke design of the ARC-8 has been used in performance wheel design for decades, as it provides a superior compromise between strength and weight, resulting in an ideal choice for a street or track wheel. All APEX wheels incorporate a BMW-specific hubcentric design, so they're a direct fit designed specifically for you.

ARC8 Wheel SizeWheel Weight
17x10" ET2518.45 lbs
17x10.5" ET2718.95 lbs
17x8.5" ET2016.5 lbs
17x8.5" ET4017.2 lbs
17x9" ET3016.5 lbs
17x9" ET4217.8 lbs
17x9.5" ET3516.95 lbs
18x10" ET2619.95 lbs
18x10.5" ET2720.45 lbs
18x8.5" ET3818.45 lbs
18x8.5" ET4518.2 lbs
18x9" ET3018.05 lbs
18x9" ET4218.7 lbs
18x9.5" ET2219.2 lbs
18x9.5" ET3518.85 lbs
18x9.5" ET5818.2 lbs
19x10 ET2521.95 lbs
19x10.5 ET2222.95 lbs
19x8.5" ET2020.7 lbs
19x8.5" ET3520.5 lbs
19x9 ET3820.7 lbs
19x9.5" ET2220.95 lbs
19x9.5" ET3320.5 lbs

The APEX ARC-8 wheel achieves its combination of strength, light weight, and affordability through flow-forming technology. By flow-forming the wheel, weight is reduced in the barrel through a process sometimes referred to as "roll forging." Roll forging, while not the same as the traditional forging, is superior to regular casting. The rolling process occurs under extreme pressure, yielding a barrel that is stronger than a standard cast wheel, with certain material properties that are similar to a standard forged wheel. This added barrel strength allows for a reduction in overall wheel weight, while not sacrificing any of the strength you'd expect from durable flow-formed wheels.

Thanks to its lightweight barrel and robust face design, the ARC-8 stands up well against the rigors of endurance racing, as well as your average street potholes. ARC8 17" wheels carry a 1,450lb load rating; ARC8 18" have a 1,550lb load rating.

Features

  • Split spoke design - superior strength and reduced weight
  • Flow-formed, roll forged barrel - superior strength and reduced weight
  • Excellent clearance for aftermarket big brake kits
  • APEX logo center cap included
  • Accepts OEM BMW center caps
  • Accepts factory lugs, wheel locks, or stud conversions
  • Tire pressure monitoring system (TPMS) compatible - not included

Priced per wheel (individually).

Note: Not all colors are available for all wheels. In 2023 APEX is replacing most Hyper Silver wheels with Race Silver (the color difference is very small). Contact us if a wheel & color combination is not listed.

These wheels, like many wheels, are not compatible with 10mm wheel spacers, which have inherent design limitations that prevent them from sitting flush. If 10mm spacers are called for we recommend using 12mm instead. The difference is minuscule.

Need help deciding on a size or offset for your BMW? No problem! Give us a call at 877.639.9648 or email us at [email protected] for assistance. We're your BMW wheel experts and are happy to help.

Please verify your specific wheel fitment before ordering. To avoid costly return shipping, or risk non-fitment, we strongly urge you to contact us first.



BMW Fitments:
1 Series
E82 / E88 (08-13) > 128i
E82 / E88 (08-13) > 135i N54 (08-10)
E82 / E88 (08-13) > 135i N55 (11-13)
E82 / E88 (08-13) > 135is N55 (11-13)
E82 / E88 (08-13) > 1M (11-12)
2 Series
F22 / F23 (2014-2021) > 228i
F22 / F23 (2014-2021) > 228i xDrive
F22 / F23 (2014-2021) > M235i
F22 / F23 (2014-2021) > M235i xDrive
F22 / F23 (2014-2021) > M235i-Racing
F22 / F23 (2014-2021) > M240i-Racing
2 Series
F87 (2016-2021) > M2 Competition S55 (2019+)
F87 (2016-2021) > M2 N55 (2016-2018)
3 Series
E30 (84-91) > 318i
E30 (84-91) > 318is
E30 (84-91) > 325e
E30 (84-91) > 325es
E30 (84-91) > 325i
E30 (84-91) > 325is
E30 (84-91) > 325ix
E30 (84-91) > M3
3 Series
E36 (92-99) > 318i M42
E36 (92-99) > 318i M44
E36 (92-99) > 318ic M42
E36 (92-99) > 318ic M44
E36 (92-99) > 318is M42
E36 (92-99) > 318is M44
E36 (92-99) > 323ic
E36 (92-99) > 323is
E36 (92-99) > 325i
E36 (92-99) > 325ic
E36 (92-99) > 325is
E36 (92-99) > 328i
E36 (92-99) > 328ic
E36 (92-99) > 328is
E36 (92-99) > M3 (1995)
E36 (92-99) > M3 (96-99)
3 Series
E36/5 (95-99) > 318ti M42
E36/5 (95-99) > 318ti M44
3 Series
E46 (99-05) > 320i
E46 (99-05) > 323Ci
E46 (99-05) > 323i
E46 (99-05) > 325Ci
E46 (99-05) > 325i
E46 (99-05) > 325xi
E46 (99-05) > 328Ci
E46 (99-05) > 328i
E46 (99-05) > 330Ci
E46 (99-05) > 330i
E46 (99-05) > 330xi
E46 (99-05) > M3
3 Series
E90 / E91 / E92 / E93 (06-13) > 323i
E90 / E91 / E92 / E93 (06-13) > 325i
E90 / E91 / E92 / E93 (06-13) > 325xi
E90 / E91 / E92 / E93 (06-13) > 328i
E90 / E91 / E92 / E93 (06-13) > 328xi
E90 / E91 / E92 / E93 (06-13) > 330i
E90 / E91 / E92 / E93 (06-13) > 330xi
E90 / E91 / E92 / E93 (06-13) > 335d
E90 / E91 / E92 / E93 (06-13) > 335i N54 (07-10)
E90 / E91 / E92 / E93 (06-13) > 335i N55 (11-13)
E90 / E91 / E92 / E93 (06-13) > 335is N54
E90 / E91 / E92 / E93 (06-13) > 335xi N54 (07-10)
E90 / E91 / E92 / E93 (06-13) > 335xi N55 (11-13)
E90 / E91 / E92 / E93 (06-13) > M3
3 Series
F30 / F31 / F34 (2012-2019) > 320i
F30 / F31 / F34 (2012-2019) > 320i xDrive
F30 / F31 / F34 (2012-2019) > 328d
F30 / F31 / F34 (2012-2019) > 328d xDrive
F30 / F31 / F34 (2012-2019) > 328i
F30 / F31 / F34 (2012-2019) > 328i xDrive
F30 / F31 / F34 (2012-2019) > 335i
F30 / F31 / F34 (2012-2019) > 335i xDrive
F30 / F31 / F34 (2012-2019) > Hybrid 3
3 Series
F80 (2015-2018) > M3 (2015-2018)
4 Series
F32 / F33 / F36 (14-20) > 428i
F32 / F33 / F36 (14-20) > 428i xDrive
F32 / F33 / F36 (14-20) > 435i
F32 / F33 / F36 (14-20) > 435i xDrive
4 Series
F82 / F83 (2015-2020) > M4 (2015-2020)
F82 / F83 (2015-2020) > M4 GTS
5 Series
E12 (77-81) > 528i
E12 (77-81) > 530i
5 Series
E28 (82-88) > 524td
E28 (82-88) > 528e
E28 (82-88) > 533i
E28 (82-88) > 535i
E28 (82-88) > M5 (87-88)
5 Series
E34 (89-95) > 525i M20
E34 (89-95) > 525i M50
E34 (89-95) > 530i
E34 (89-95) > 535i
E34 (89-95) > 540i
E34 (89-95) > M5 (91-95)
5 Series
E60 / E61 (04-10) > 525i M54 (2004-2005)
E60 / E61 (04-10) > 525i N52 (2006-2007)
E60 / E61 (04-10) > 525xi N52 (2006-2007)
E60 / E61 (04-10) > 528i
E60 / E61 (04-10) > 528xi
E60 / E61 (04-10) > 530i M54 (2004-2005)
E60 / E61 (04-10) > 530i N52 (2006-2007)
E60 / E61 (04-10) > 530xi N52 (2006-2007)
E60 / E61 (04-10) > 535i
E60 / E61 (04-10) > 535xi
E60 / E61 (04-10) > 545i
E60 / E61 (04-10) > 550i
E60 / E61 (04-10) > M5
5 Series
F10 / F11 (11-16) > 528i N20 (2012-2016)
F10 / F11 (11-16) > 528i N52 (2011)
F10 / F11 (11-16) > 528i xDrive N20 (2012-2016)
F10 / F11 (11-16) > 535d
F10 / F11 (11-16) > 535d xDrive
F10 / F11 (11-16) > 535i
F10 / F11 (11-16) > 535i xDrive
F10 / F11 (11-16) > 550i
F10 / F11 (11-16) > 550i xDrive
F10 / F11 (11-16) > Hybrid 5
F10 / F11 (11-16) > M5 (2013-2016)
6 Series
E24 (77-89) > 630CSi
E24 (77-89) > 633CSi
E24 (77-89) > 635CSi
E24 (77-89) > M6
6 Series
E63 / E64 (04-10) > 645Ci
E63 / E64 (04-10) > 650i
E63 / E64 (04-10) > M6
6 Series
F12 / F13 (12-18) > 640i
F12 / F13 (12-18) > 650i
F12 / F13 (12-18) > 650i xDrive
F12 / F13 (12-18) > M6
7 Series
E23 (77-87) > 733i
E23 (77-87) > 735i
7 Series
E32 (88-94) > 735i
E32 (88-94) > 735iL
E32 (88-94) > 740i
E32 (88-94) > 740iL
E32 (88-94) > 750iL
7 Series
E38 (95-01) > 740i
E38 (95-01) > 740iL
E38 (95-01) > 750iL
7 Series
E65 / E66 (02-08) > 745Li
E65 / E66 (02-08) > 745i
E65 / E66 (02-08) > 750Li
E65 / E66 (02-08) > 750i
E65 / E66 (02-08) > 760Li
7 Series
F01 / F02 (2009-2015) > 740Li
F01 / F02 (2009-2015) > 740i
F01 / F02 (2009-2015) > 750Li
F01 / F02 (2009-2015) > 750Li xDrive
F01 / F02 (2009-2015) > 750i
F01 / F02 (2009-2015) > 760Li
8 Series
E31 (91-97) > 840Ci
E31 (91-97) > 850CSi
E31 (91-97) > 850Ci
X1 Series
E84 X1 (2013-2015) > X1 28i
E84 X1 (2013-2015) > X1 28i xDrive
E84 X1 (2013-2015) > X1 35i xDrive
Z Series
E36/7 / E36/8 Z3 (96-02) > Z3 1.9
E36/7 / E36/8 Z3 (96-02) > Z3 2.3
E36/7 / E36/8 Z3 (96-02) > Z3 2.5
E36/7 / E36/8 Z3 (96-02) > Z3 2.8 97-98
E36/7 / E36/8 Z3 (96-02) > Z3 2.8 99-00
E36/7 / E36/8 Z3 (96-02) > Z3 3.0
E36/7 / E36/8 Z3 (96-02) > Z3 M - S52
E36/7 / E36/8 Z3 (96-02) > Z3 M - S54
Z Series
E52 Z8 (00-03) > Z8 Roadster (2000-2003)
Z Series
E85 / E86 Z4 (03-08) > Z4 2.5i M54
E85 / E86 Z4 (03-08) > Z4 3.0i M54
E85 / E86 Z4 (03-08) > Z4 3.0i N52
E85 / E86 Z4 (03-08) > Z4 3.0si N52
E85 / E86 Z4 (03-08) > Z4 M
Z Series
E89 Z4 (2009-2016) > Z4 sDrive28i
E89 Z4 (2009-2016) > Z4 sDrive30i
E89 Z4 (2009-2016) > Z4 sDrive35i
E89 Z4 (2009-2016) > Z4 sDrive35is
